FUTV4406 IP to ISDB-T Modulator (1000M IP,4*IP in, 4*IP out)with network management lanyue

FOB Reference Price:Get Latest Price
$1,800.00 - $2,250.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
FMUSER
Model Number:
FUTV4406
IP Input:
4* IP (MPTS/SPTS) input over UDP (Unitcast/Multicast)
IP Input2:
IGMP Snooping: v2, v3
RF Output:
ARIB STD-B31
Constellation:
DQPSK, QPSK, 16QAM, 64QAM
Output:
30~1000MHz, 1KHz step
IP Output:
4*IP output, one for one with the 4 IP input
System:
LCD/keyboard operating and Web-based NMS support
System2:
Ethernet software upgrading
Dimension:
482mm*300mm*44mm (W*D*H)
Weight:
2.3kg
Supply Ability
Supply Ability:
1000 Set/Sets per Month
Packaging & Delivery
Packaging Details
Dimensions:44mm*482mm*430mm(H*W*D)
Approx weight:4Kg
Neutral Pack
Port
Guangzhou
Lead Time :
7-15days



Contact Us

Please contact the following staff for instant help with product user manual, datasheet and updated wholesale price.

Email: kitmanlaw(at)gmail.com

Skype: lanyue99991

Wechat: +86 13602420401

Whatsapp: +86 13602420401

Tel:+86 13602420401 (Monday~Friday: 9:00 ~ 18:00 (+8 China ) )

Working Time

09:00--18:00 Beijing
17:00--2:00 San Francisco

19:00--4:00 New York

21:00--6:00 Paris

04:00--13:00 Moscow

12:00--21:00 Sydney

02:00--11:00am Congo ( Africa )



Quality  Control





OEM Order Welcomed






Production Intruduction



FUTV4406 IP to ISDB-T Modulator (1000M IP,4*IP in, 4*IP out)with network management

R: V20150821-17-03Data sheet

 Input:ASI, IP, Tuner   Output:DVB-C






Overview



FUTV4406 IP to ISDB-T modulator is a high performance modulator developed according to ARIB STD-831 standard. It provides a more powerful receiving ability to simultaneously process 4 IP streams inputting from encoder, multiplexer, gateway and etc head-end. It outputs digital RF after multiplexing process.

For management and operation, this device supports local and remote control through a web-based NMS system.



Features



*Complying with ARIB STD-831 standard

*1000M IP port, 4 IP streams input
*Support 4 IP output
*Programs output through RF with multiplexing
*Dual adjacent carriers output
*RF Output frequency range: 30MHz~1000MHz in 1 kHz step
*Support PID remapping
*LCD/keyboard and Web-based NMS operation





Technical Specifications





IP Input

4* IP (MPTS/SPTS) input over UDP (Unitcast/Multicast) (1000M port based Ethernet)

IGMP Snooping: v2, v3

RF Output

Standard

ARIB STD-B31

Bandwidth

6M

Constellation

DQPSK, QPSK, 16QAM, 64QAM

Guard Interval

1/32, 1/16, 1/8, 1/4.

Transmission Mode

2K, 4K, 8K

FEC

1/2, 2/3, 3/4, 5/6, 7/8

MER

>=42dB

Output

30~1000MHz, 1KHz step

RF output level

-30~ -10dbm (77~97 dbµV), 0.1db step

IP Output

4*IP output, one for one with the 4 IP input

System

LCD/keyboard operating and Web-based NMS support

Ethernet software upgrading

General

Dimension

482mm*300mm*44mm (W*D*H)

Weight

2.3kg

Temperature

0~45C(Operation); -20~80C(Storage)

Power

AC 110V+-10%, 50/60Hz; or AC 220V+-10%, 50/60Hz

Consumption

25W







Principle Chart









Solutions



Kindly contact me to send you more solutions for DVB-C, DVB-S, DVB-T, Cable QAM System for Hotel ,Microwave , Radio reporter system...etc



Applications



About US





Contact US



1.FAQ:Where is your company located? How can I visit your company?

A:Our factory is located in Tian He District, Guang Zhou City, China, it's about 25 mins away from Canton Fair Center and 15 mins from Guang Zhou Eastern Station, all our clients, from home or abroad, are warmly welcome to take a visit here!

You can search this numbers " 23.127,113.332 " in google map , then you can find our fmuser office .



2.FAQ:How does your company do regarding quality control?

A:Quality is very important and always the priority of our inspection system. FMUSER team members always pay great attention to quality control from the very beginning to the end.

All machine will be Aging work 40days before shipment.


3.FAQ:Can I get some samples?
A: Yes, sure, we are honored to offer you samples, sample fee can be discussed.

4.FAQ:What is your mode of transportation?
A: We ship via International Express like FedEx, UPS, DHL, TNT, other ways designated by customers are also optional.

5.FAQ:Could you pls make OEM for us?
A: Surely yes.We provide the service of replacing your logo and company name on box, product and software interface
of the device .

6.FAQ:What's your payment method supported?
A: We accept T/T, Paypal, Western Union, MoneyGram etc.

7.FAQ:What about your warranty?

A: We provide 1 year quality warranty for our main devices, accessories are not within this range, but our accessories are endurable enough to use for long time.



FMUSER International Group Inc is a comapny dedicated to FM and TV broadcasting equipments and relevant accessories. All of our products are fully inpsected before shipping, and sold to many countries all over the world. We will make effort to become a super supplier in the global FM and TV filed.
